STANDARD FEATURES
Compact design
Simple, easy to use controls
Rotationally molded housing
200lb of variable pad pressure
Vairable speed transaxle drive
Forward and reverse drive
| Solution Tank |
30gal (115L) |
| Recovery Tank |
28gal (106L) |
| Cleaning Path |
32" (80cm) |
| Pad Diameter |
16" (40.6 cm) x2 |
| Pad Pressure |
Up to 200lb (90.7 kg) |
| Squeegee Width |
40" (101.6cm) |
| Speed Control |
Variable fwd/rev |
| Coverage Rate |
34,560 sq'/hr |
| Drive System |
1/2 hp Transaxle |
| Brush Motors |
1 hp, 200 rpm |
| Vacuum Motor |
3-stage |
| Waterlift |
73" (186cm) |
| Batteries |
185a/h (x3) |
| Run Time Per Charge |
3.5-4 hrs (est w/185 a/h) |
| Weight w/o Batteries |
440.5 lb (200 kg) |
| Length |
66.5" (169cm) |
| Width |
41.3" (105cm) |
| Height |
42.9" (109cm) |
| |
|
OPTIONAL ACCESSORIES
Poly Scrub Brush VFB4330 (requires 2)
H.D. cast aluminum squeegee assembly |
